VERTICAL LIFT MODELS

Our vertical lifts options range between 1600 lb and 8000 lb capacities and can be used with all different types of hull designs including pontoons and tritoons. These lifts are freestanding and do not require any type of anchoring. The lifts are designed to be placed along side of a dock or seawall.

Our lifts utilize an I-beam platform design for strength and reliability, but they are also designed for lower water application and allows the cradle to drop down into the lower framework. This allows our lifts to work as well as V-rack boat lift designs.

VerticalLiftModels_BodyHeader



KEY VERTICAL LIFT COMPONENTS

  • Vinyl and Aluminum Hull Bunks – This design allows the bunk to contour to the hull of your boat and the vinyl cap will not trap debris like carpeted bunks. The bunks are also little to no maintenance with the vinyl and aluminum combination.
  • I-Beam Cradle Design – A very strong platform design using a straight I-Beam extrusion. Our design drops into the lower framework allowing the cradle to get just as low as a V-style cradle design.
  • Patented Double Reduction Winch – Easier to crank than other comparable capacity lifts.

Below you will find our vertical lift models along with some lift specifications. All vertical models come standard with vinyl and aluminum hull bunks, stainless steel cables, galvanized steel winch cable and zinc plated fasteners.

Model

Capacity

Inside Beam Width

Length

Weight

Cradle Travel

Leveling Legs

Bunks

MH-V25108 2500 lb 108″ 108″ 325 lbs 52″ 30″ 9′
MH-V35108 3500 lb 108″ 120″ 380 lbs 64″ 54″ 10′
MH-V35120 3500 lb 120″ 120″ 420 lbs 64″ 54″ 10′
MH-V45108 4500 lb 108″ 120″ 470 lbs 64″ 54″ 10′
MH-V45114 4500 lb 114″ 120″ 495 lbs 64″ 54″ 10′
MH-V45120 4500 lb 120″ 120″ 500 lbs 64″ 54″ 10′
MH-V60120 6000 lb 120″ 132″ 620 lbs 60″ 30″ 12′
MH-V60132 6000 lb 132″ 132″ 635 lbs 60″ 30″ 12′
MH-V60144* 6000 lb 144″ 132″ 680 lbs 60″ 30″ 12′
MH-V70144* 7000 lb 144″  168″ 835 lbs 60″  30″ 12′
MH-V80120 8000 lb 120″  132″ 750 lbs 60″ 30″ 12′
MH-V40120HL High Lift 4000 lb 120″ 120″ 580 lbs 84″  54″ 10′
MH-V60120HL High Lift 6000 lb 120″  132″ 775 lbs 84″  30″  12′
 *For Pontoon Boats Only

[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column width=”1/2″][vc_single_image image=”468″ border_color=”grey” img_link_target=”_self” img_size=”378×270″][/vc_column][vc_column width=”1/2″][vc_single_image image=”469″ alignment=”right” border_color=”grey” img_link_target=”_self” img_size=”378×270″][/vc_column][/vc_row][vc_row][vc_column width=”1/1″][vc_column_text]ACCESSORIES FOR VERTICAL LIFTS

Accessory Type Description Fits Lifts
Standard Canopy Standard canopy frame, legs and vinyl cover Vertical
High Top Canopy High Top canopy frame with legs and cover Vertical
Carpeted Load Guides Full Length Carpeted Guides Vertical
Foam Load Guides Foam covered uprights, covers available Vertical
Pontoon Guides Angled Bracket with vinyl and aluminum guide runner Vertical
Motor Stop Used with outboards and I/O’s to protect them from making contact with rear crossmember. Vertical

[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column width=”1/1″][vc_column_text]

SAFETY AND GENERAL INFORMATION

[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column width=”7/12″][vc_column_text]Loading A Vertical Lift

When loading a boat on the hoist you should have close to equal the weight on front and back of your hoist. Correct loading typically will have the rear of boat (where the motor is located) close to the rear of the hoist. Exceptions could be either a ski or sail boat.

If too much weight is on the front or back of the hoist the cables could become bound on the pulleys, which can cause problems when lowering your boat. The hoist may lower only on one corner. If this happens, try using a counter weight in the light end of the boat to ensure equal weight distribution. This should cure the problem.

Canopy And Wind

The hoist becomes much lighter when removing the boat from it. So it is important to keep in mind that when your boat is not on the hoist strong winds can move, tip over or even pick it up out of the water.[/vc_column_text][/vc_column][vc_column width=”5/12″][vc_single_image image=”448″ alignment=”right” border_color=”grey” img_link_target=”_self” img_size=”300×161″][vc_single_image image=”447″ alignment=”right” border_color=”grey” img_link_target=”_self” img_size=”300×161″ style=”vc_box_shadow”][/vc_column][/vc_row][vc_row][vc_column width=”1/1″][vc_column_text]Our Craftlander line of products are only sold through established dealers.
Please call  (989) 275-8054  or send us an email to obtain the name of the dealer near you. eMail: sales@nucraftonline.com
